Product Details

Specification Details
Product Type
Home Solar Battery / Solar Energy Storage System
Battery Capacity 3.84 kWh
Battery Chemistry LFP (LiFePO₄)
Maximum AC Charging Input 1,200 W
Rated AC Output 1,200 W
Maximum Supported Output
Up to 2,300 W under specified grid-connected/bypass conditions
Number of MPPTs 4
Maximum Solar Input Power 2,000 W (500 W × 4)
MPPT Voltage Range 15–60 V DC
Maximum PV Input Voltage 60 V DC
Maximum PV Input Current 4 × 14 A
Maximum PV Short-Circuit Current 4 × 20 A
Grid-Tied AC Output
800 W or 600 W, depending on model variant
Battery Cycle Life 6,000 cycles to 70% remaining capacity
Expandable Capacity
Supports compatible STREAM Series units or STREAM Extra Batteries
Connectivity Wi-Fi / Bluetooth
Ingress Protection IP65
Operating Temperature −20°C to 55°C
Low-Temperature Charging
Self-heating/charging activation specified at 5°C or below
Noise Level Below 30 dB
Off-Grid Capability
Yes, for compatible appliances and supported configurations
  • STREAM Solar Panel Extension Cable
  • STREAM AC Cable
  • PV Wrench
  • Mounting Bracket
  • Locking Brackets
  • Safety Instruction
  • Installation Guide
  • Warranty Card
  • 5 Year Warranty | Human Error Not Covered

It supports up to 2,000W of solar input through four independent MPPTs, with a maximum of 500W per MPPT.

It provides up to 1,200W rated AC output. Up to 2,300W is specified for supported devices under certain grid-connected or bypass conditions.
